	Civil War Weapons, all pre 1898
	by Harry Ridgeway

Breechloader, Burnside single shot percussion carbine, 1856 patent date, lever is hinged with guide screw, 5th model, .54cal. . Burnside carbine employed an unusual cone shaped metal cartridge for use in a percussion system. Period literature refers to the Model 1863, although none are marked with this date and collectors have referred to the model generally as 5th model, however, that is a collector term of convenience and not a contemporary designation. This model was in the field during the 1864 cavalry campaigns. Serial numbers continued from 4th model to about 40,000 overall, production 1863 or 1864. This model represented only modest improvements over the earlier models, most notably being the placement of a guide screw on the right side in the middle of the receiver, this improvement facilitated smoother operation during loading. The loading lever was hinged starting with the 4th model, however the lever had a tendency to jam if not cleanly released. The addition of the guide screw enabled the hinged receiver to be raised or lowered without catching and jamming. The barrel is stamped Cast Steel, followed by a date, the date is weak or missing on most, this because the long and narrow stamp had to be centered on a round barrel, apparently most were not centered. Both the 1862 or the 1864 date seem to have been used. Manufactured by Burnside Rifle Co., Providence, Rhode Island, General Ambrose Burnside, was an official in the company before the war but was not involved in wartime development of the weapon. Marks on top of frame BURNSIDE PATENT / MARCH 25, 1856. Barrel is marked CAST STEEL (date usually obliterated) . Lock marked, BURNSIDE RIFLE CO. / PROVIDENCE = R. I. . Serial number normally appears three times, on the top of the breech, top of the receiver, and inside (can be viewed by opening the breech). Cartouches in the wood on the left side indicate government inspection, additional inspector marks may be found on other parts. Standard features include: iron buttplate, single iron barrel band, saddle riding bar and ring on left side, strap hook on bottom of butt, double hinged iron loading lever also serves as a trigger guard, hinged sight, chamber tapered for unique Burnside metal cartridge with a priming hole in the bottom for percussion. Research Center: Weapon2065-Breechloader-Burnside-Carbine-Model-5 . Reference: Flayderman 9B-046. Barrel length 21in. Details click: http://relicman.com/weapons/Weapon2065-Breechloader-Burnside-Carbine-Model-5.html

W1354 ### Breechloader, Burnside single shot percussion carbine, 1856 patent date, lever is hinged with guide screw, 5th model, .54cal. (sn# 19713) . Burnside carbine employed an unusual cone shaped metal cartridge for use in a percussion system. Period literature refers to the Model 1863, although none are marked with this date and collectors have referred to the model generally as 5th model, however, that is a collector term of convenience and not a contemporary designation. This model was in the field during the 1864 cavalry campaigns. Serial numbers continued from 4th model to about 40,000 overall, production 1863 or 1864. This model represented only modest improvements over the earlier models, most notably being the placement of a guide screw on the right side in the middle of the receiver, this improvement facilitated smoother operation during loading. The loading lever was hinged starting with the 4th model, however the lever had a tendency to jam if not cleanly released. The addition of the guide screw enabled the hinged receiver to be raised or lowered without catching and jamming. The barrel is stamped Cast Steel, followed by a date, the date is weak or missing on most, this because the long and narrow stamp had to be centered on a round barrel, apparently most were not centered. Both the 1862 or the 1864 date seem to have been used. Manufactured by Burnside Rifle Co., Providence, Rhode Island, General Ambrose Burnside, was an official in the company before the war but was not involved in wartime development of the weapon. Marks on top of frame BURNSIDE PATENT / MARCH 25, 1856. Barrel is marked CAST STEEL (date usually obliterated) . Lock marked, BURNSIDE RIFLE CO. / PROVIDENCE = R. I. . Serial number normally appears three times, on the top of the breech, top of the receiver, and inside (can be viewed by opening the breech). Cartouches in the wood on the left side indicate government inspection, additional inspector marks may be found on other parts. Standard features include: iron buttplate, single iron barrel band, saddle riding bar and ring on left side, strap hook on bottom of butt, double hinged iron loading lever also serves as a trigger guard, hinged sight, chamber tapered for unique Burnside metal cartridge with a priming hole in the bottom for percussion. Research Center: Weapon2065-Breechloader-Burnside-Carbine-Model-5 . Reference: Flayderman 9B-046. Barrel length 21in. Serial number, 19713.

W1374 ### Breechloader, Burnside single shot percussion carbine, 1856 patent date, lever is hinged with guide screw, 5th model, .54cal. (sn# 23701) . Burnside carbine employed an unusual cone shaped metal cartridge for use in a percussion system. Period literature refers to the Model 1863, although none are marked with this date and collectors have referred to the model generally as 5th model, however, that is a collector term of convenience and not a contemporary designation. This model was in the field during the 1864 cavalry campaigns. Serial numbers continued from 4th model to about 40,000 overall, production 1863 or 1864. This model represented only modest improvements over the earlier models, most notably being the placement of a guide screw on the right side in the middle of the receiver, this improvement facilitated smoother operation during loading. The loading lever was hinged starting with the 4th model, however the lever had a tendency to jam if not cleanly released. The addition of the guide screw enabled the hinged receiver to be raised or lowered without catching and jamming. The barrel is stamped Cast Steel, followed by a date, the date is weak or missing on most, this because the long and narrow stamp had to be centered on a round barrel, apparently most were not centered. Both the 1862 or the 1864 date seem to have been used. Manufactured by Burnside Rifle Co., Providence, Rhode Island, General Ambrose Burnside, was an official in the company before the war but was not involved in wartime development of the weapon. Marks on top of frame BURNSIDE PATENT / MARCH 25, 1856. Barrel is marked CAST STEEL (date usually obliterated) . Lock marked, BURNSIDE RIFLE CO. / PROVIDENCE = R. I. . Serial number normally appears three times, on the top of the breech, top of the receiver, and inside (can be viewed by opening the breech). Cartouches in the wood on the left side indicate government inspection, additional inspector marks may be found on other parts. Standard features include: iron buttplate, single iron barrel band, saddle riding bar and ring on left side, strap hook on bottom of butt, double hinged iron loading lever also serves as a trigger guard, hinged sight, chamber tapered for unique Burnside metal cartridge with a priming hole in the bottom for percussion. Research Center: Weapon2065-Breechloader-Burnside-Carbine-Model-5 . Reference: Flayderman 9B-046. Barrel length 21in. Serial number, 23701.

W1373 ### Breechloader, Burnside single shot percussion carbine, 1856 patent date, lever is hinged with guide screw, 5th model, .54cal. (sn# 23978) . Burnside carbine employed an unusual cone shaped metal cartridge for use in a percussion system. Period literature refers to the Model 1863, although none are marked with this date and collectors have referred to the model generally as 5th model, however, that is a collector term of convenience and not a contemporary designation. This model was in the field during the 1864 cavalry campaigns. Serial numbers continued from 4th model to about 40,000 overall, production 1863 or 1864. This model represented only modest improvements over the earlier models, most notably being the placement of a guide screw on the right side in the middle of the receiver, this improvement facilitated smoother operation during loading. The loading lever was hinged starting with the 4th model, however the lever had a tendency to jam if not cleanly released. The addition of the guide screw enabled the hinged receiver to be raised or lowered without catching and jamming. The barrel is stamped Cast Steel, followed by a date, the date is weak or missing on most, this because the long and narrow stamp had to be centered on a round barrel, apparently most were not centered. Both the 1862 or the 1864 date seem to have been used. Manufactured by Burnside Rifle Co., Providence, Rhode Island, General Ambrose Burnside, was an official in the company before the war but was not involved in wartime development of the weapon. Marks on top of frame BURNSIDE PATENT / MARCH 25, 1856. Barrel is marked CAST STEEL (date usually obliterated) . Lock marked, BURNSIDE RIFLE CO. / PROVIDENCE = R. I. . Serial number normally appears three times, on the top of the breech, top of the receiver, and inside (can be viewed by opening the breech). Cartouches in the wood on the left side indicate government inspection, additional inspector marks may be found on other parts. Standard features include: iron buttplate, single iron barrel band, saddle riding bar and ring on left side, strap hook on bottom of butt, double hinged iron loading lever also serves as a trigger guard, hinged sight, chamber tapered for unique Burnside metal cartridge with a priming hole in the bottom for percussion. Research Center: Weapon2065-Breechloader-Burnside-Carbine-Model-5 . Reference: Flayderman 9B-046. Barrel length 21in. Serial number, 23978.

W1387 ### Breechloader, Burnside single shot percussion carbine, 1856 patent date, lever is hinged with guide screw, 5th model, .54cal. (sn# 26706) . Burnside carbine employed an unusual cone shaped metal cartridge for use in a percussion system. Period literature refers to the Model 1863, although none are marked with this date and collectors have referred to the model generally as 5th model, however, that is a collector term of convenience and not a contemporary designation. This model was in the field during the 1864 cavalry campaigns. Serial numbers continued from 4th model to about 40,000 overall, production 1863 or 1864. This model represented only modest improvements over the earlier models, most notably being the placement of a guide screw on the right side in the middle of the receiver, this improvement facilitated smoother operation during loading. The loading lever was hinged starting with the 4th model, however the lever had a tendency to jam if not cleanly released. The addition of the guide screw enabled the hinged receiver to be raised or lowered without catching and jamming. The barrel is stamped Cast Steel, followed by a date, the date is weak or missing on most, this because the long and narrow stamp had to be centered on a round barrel, apparently most were not centered. Both the 1862 or the 1864 date seem to have been used. Manufactured by Burnside Rifle Co., Providence, Rhode Island, General Ambrose Burnside, was an official in the company before the war but was not involved in wartime development of the weapon. Marks on top of frame BURNSIDE PATENT / MARCH 25, 1856. Barrel is marked CAST STEEL (date usually obliterated) . Lock marked, BURNSIDE RIFLE CO. / PROVIDENCE = R. I. . Serial number normally appears three times, on the top of the breech, top of the receiver, and inside (can be viewed by opening the breech). Cartouches in the wood on the left side indicate government inspection, additional inspector marks may be found on other parts. Standard features include: iron buttplate, single iron barrel band, saddle riding bar and ring on left side, strap hook on bottom of butt, double hinged iron loading lever also serves as a trigger guard, hinged sight, chamber tapered for unique Burnside metal cartridge with a priming hole in the bottom for percussion. Research Center: Weapon2065-Breechloader-Burnside-Carbine-Model-5 . Reference: Flayderman 9B-046. Barrel length 21in. Serial number, 26706.

W1355 ### Breechloader, Burnside single shot percussion carbine, 1856 patent date, lever is hinged with guide screw, 5th model, .54cal. (sn# 26964) . Burnside carbine employed an unusual cone shaped metal cartridge for use in a percussion system. Period literature refers to the Model 1863, although none are marked with this date and collectors have referred to the model generally as 5th model, however, that is a collector term of convenience and not a contemporary designation. This model was in the field during the 1864 cavalry campaigns. Serial numbers continued from 4th model to about 40,000 overall, production 1863 or 1864. This model represented only modest improvements over the earlier models, most notably being the placement of a guide screw on the right side in the middle of the receiver, this improvement facilitated smoother operation during loading. The loading lever was hinged starting with the 4th model, however the lever had a tendency to jam if not cleanly released. The addition of the guide screw enabled the hinged receiver to be raised or lowered without catching and jamming. The barrel is stamped Cast Steel, followed by a date, the date is weak or missing on most, this because the long and narrow stamp had to be centered on a round barrel, apparently most were not centered. Both the 1862 or the 1864 date seem to have been used. Manufactured by Burnside Rifle Co., Providence, Rhode Island, General Ambrose Burnside, was an official in the company before the war but was not involved in wartime development of the weapon. Marks on top of frame BURNSIDE PATENT / MARCH 25, 1856. Barrel is marked CAST STEEL (date usually obliterated) . Lock marked, BURNSIDE RIFLE CO. / PROVIDENCE = R. I. . Serial number normally appears three times, on the top of the breech, top of the receiver, and inside (can be viewed by opening the breech). Cartouches in the wood on the left side indicate government inspection, additional inspector marks may be found on other parts. Standard features include: iron buttplate, single iron barrel band, saddle riding bar and ring on left side, strap hook on bottom of butt, double hinged iron loading lever also serves as a trigger guard, hinged sight, chamber tapered for unique Burnside metal cartridge with a priming hole in the bottom for percussion. Research Center: Weapon2065-Breechloader-Burnside-Carbine-Model-5 . Reference: Flayderman 9B-046. Barrel length 21in. Serial number, 26964.

W1388 ### Breechloader, Burnside single shot percussion carbine, 1856 patent date, lever is hinged with guide screw, 5th model, .54cal. (sn# 27997) . Burnside carbine employed an unusual cone shaped metal cartridge for use in a percussion system. Period literature refers to the Model 1863, although none are marked with this date and collectors have referred to the model generally as 5th model, however, that is a collector term of convenience and not a contemporary designation. This model was in the field during the 1864 cavalry campaigns. Serial numbers continued from 4th model to about 40,000 overall, production 1863 or 1864. This model represented only modest improvements over the earlier models, most notably being the placement of a guide screw on the right side in the middle of the receiver, this improvement facilitated smoother operation during loading. The loading lever was hinged starting with the 4th model, however the lever had a tendency to jam if not cleanly released. The addition of the guide screw enabled the hinged receiver to be raised or lowered without catching and jamming. The barrel is stamped Cast Steel, followed by a date, the date is weak or missing on most, this because the long and narrow stamp had to be centered on a round barrel, apparently most were not centered. Both the 1862 or the 1864 date seem to have been used. Manufactured by Burnside Rifle Co., Providence, Rhode Island, General Ambrose Burnside, was an official in the company before the war but was not involved in wartime development of the weapon. Marks on top of frame BURNSIDE PATENT / MARCH 25, 1856. Barrel is marked CAST STEEL (date usually obliterated) . Lock marked, BURNSIDE RIFLE CO. / PROVIDENCE = R. I. . Serial number normally appears three times, on the top of the breech, top of the receiver, and inside (can be viewed by opening the breech). Cartouches in the wood on the left side indicate government inspection, additional inspector marks may be found on other parts. Standard features include: iron buttplate, single iron barrel band, saddle riding bar and ring on left side, strap hook on bottom of butt, double hinged iron loading lever also serves as a trigger guard, hinged sight, chamber tapered for unique Burnside metal cartridge with a priming hole in the bottom for percussion. Research Center: Weapon2065-Breechloader-Burnside-Carbine-Model-5 . Reference: Flayderman 9B-046. Barrel length 21in. Serial number, 27997.

W1356 ### Breechloader, Burnside single shot percussion carbine, 1856 patent date, lever is hinged with guide screw, 5th model, .54cal. (sn# 29271) . Burnside carbine employed an unusual cone shaped metal cartridge for use in a percussion system. Period literature refers to the Model 1863, although none are marked with this date and collectors have referred to the model generally as 5th model, however, that is a collector term of convenience and not a contemporary designation. This model was in the field during the 1864 cavalry campaigns. Serial numbers continued from 4th model to about 40,000 overall, production 1863 or 1864. This model represented only modest improvements over the earlier models, most notably being the placement of a guide screw on the right side in the middle of the receiver, this improvement facilitated smoother operation during loading. The loading lever was hinged starting with the 4th model, however the lever had a tendency to jam if not cleanly released. The addition of the guide screw enabled the hinged receiver to be raised or lowered without catching and jamming. The barrel is stamped Cast Steel, followed by a date, the date is weak or missing on most, this because the long and narrow stamp had to be centered on a round barrel, apparently most were not centered. Both the 1862 or the 1864 date seem to have been used. Manufactured by Burnside Rifle Co., Providence, Rhode Island, General Ambrose Burnside, was an official in the company before the war but was not involved in wartime development of the weapon. Marks on top of frame BURNSIDE PATENT / MARCH 25, 1856. Barrel is marked CAST STEEL (date usually obliterated) . Lock marked, BURNSIDE RIFLE CO. / PROVIDENCE = R. I. . Serial number normally appears three times, on the top of the breech, top of the receiver, and inside (can be viewed by opening the breech). Cartouches in the wood on the left side indicate government inspection, additional inspector marks may be found on other parts. Standard features include: iron buttplate, single iron barrel band, saddle riding bar and ring on left side, strap hook on bottom of butt, double hinged iron loading lever also serves as a trigger guard, hinged sight, chamber tapered for unique Burnside metal cartridge with a priming hole in the bottom for percussion. Research Center: Weapon2065-Breechloader-Burnside-Carbine-Model-5 . Reference: Flayderman 9B-046. Barrel length 21in. Serial number, 29271.

W0848 ### Breechloader, Burnside single shot percussion carbine, 1856 patent date, lever is hinged with guide screw, 5th model, .54cal. (sn# 29642) . Burnside carbine employed an unusual cone shaped metal cartridge for use in a percussion system. Period literature refers to the Model 1863, although none are marked with this date and collectors have referred to the model generally as 5th model, however, that is a collector term of convenience and not a contemporary designation. This model was in the field during the 1864 cavalry campaigns. Serial numbers continued from 4th model to about 40,000 overall, production 1863 or 1864. This model represented only modest improvements over the earlier models, most notably being the placement of a guide screw on the right side in the middle of the receiver, this improvement facilitated smoother operation during loading. The loading lever was hinged starting with the 4th model, however the lever had a tendency to jam if not cleanly released. The addition of the guide screw enabled the hinged receiver to be raised or lowered without catching and jamming. The barrel is stamped Cast Steel, followed by a date, the date is weak or missing on most, this because the long and narrow stamp had to be centered on a round barrel, apparently most were not centered. Both the 1862 or the 1864 date seem to have been used. Manufactured by Burnside Rifle Co., Providence, Rhode Island, General Ambrose Burnside, was an official in the company before the war but was not involved in wartime development of the weapon. Marks on top of frame BURNSIDE PATENT / MARCH 25, 1856. Barrel is marked CAST STEEL (date usually obliterated) . Lock marked, BURNSIDE RIFLE CO. / PROVIDENCE = R. I. . Serial number normally appears three times, on the top of the breech, top of the receiver, and inside (can be viewed by opening the breech). Cartouches in the wood on the left side indicate government inspection, additional inspector marks may be found on other parts. Standard features include: iron buttplate, single iron barrel band, saddle riding bar and ring on left side, strap hook on bottom of butt, double hinged iron loading lever also serves as a trigger guard, hinged sight, chamber tapered for unique Burnside metal cartridge with a priming hole in the bottom for percussion. Research Center: Weapon2065-Breechloader-Burnside-Carbine-Model-5 . Reference: Flayderman 9B-046. Barrel length 21in. Serial number, 29642.

W1288 ### Breechloader, Burnside single shot percussion carbine, 1856 patent date, lever is hinged with guide screw, 5th model, .54cal. (sn# 39227) . Burnside carbine employed an unusual cone shaped metal cartridge for use in a percussion system. Period literature refers to the Model 1863, although none are marked with this date and collectors have referred to the model generally as 5th model, however, that is a collector term of convenience and not a contemporary designation. This model was in the field during the 1864 cavalry campaigns. Serial numbers continued from 4th model to about 40,000 overall, production 1863 or 1864. This model represented only modest improvements over the earlier models, most notably being the placement of a guide screw on the right side in the middle of the receiver, this improvement facilitated smoother operation during loading. The loading lever was hinged starting with the 4th model, however the lever had a tendency to jam if not cleanly released. The addition of the guide screw enabled the hinged receiver to be raised or lowered without catching and jamming. The barrel is stamped Cast Steel, followed by a date, the date is weak or missing on most, this because the long and narrow stamp had to be centered on a round barrel, apparently most were not centered. Both the 1862 or the 1864 date seem to have been used. Manufactured by Burnside Rifle Co., Providence, Rhode Island, General Ambrose Burnside, was an official in the company before the war but was not involved in wartime development of the weapon. Marks on top of frame BURNSIDE PATENT / MARCH 25, 1856. Barrel is marked CAST STEEL (date usually obliterated) . Lock marked, BURNSIDE RIFLE CO. / PROVIDENCE = R. I. . Serial number normally appears three times, on the top of the breech, top of the receiver, and inside (can be viewed by opening the breech). Cartouches in the wood on the left side indicate government inspection, additional inspector marks may be found on other parts. Standard features include: iron buttplate, single iron barrel band, saddle riding bar and ring on left side, strap hook on bottom of butt, double hinged iron loading lever also serves as a trigger guard, hinged sight, chamber tapered for unique Burnside metal cartridge with a priming hole in the bottom for percussion. Research Center: Weapon2065-Breechloader-Burnside-Carbine-Model-5 . Reference: Flayderman 9B-046. Barrel length 21in. Serial number, 39227.

This is the "Ridgeway Civil War Research Center", a research tool for educational purposes only, and is provided at no cost to the reader. Some of the relics listed are retained in the author's collection, most reside in other collections and are not owned by the author. None of the items listed in this section are for sale, please refer to relicman.com sales listings for items offered for sale. This is a work in progress, I list items as I get to them, there are many patterns that are not listed yet, this list will be regularly updated as I get pictures and descriptions for more items. I will also correct mistakes, so if you see any please tell me. All items listed are believed to be authentic to the Civil War or as otherwise described. Any excavated relics have been recovered from private property with owners permission.This information is available for research purposes, pictures may be used by permission only.

All weapons listed on this webpage are strictly manufactured before 1898, and are considered unsafe for actual use. These are antique collectible weapons of the Civil War (most are pre 1865, unless I state otherwise) and actual firing of these weapons is not recommended for any purpose whatsoever! Because these are all "pre 1898" weapons, no licenses are required for ownership, but common sense and good judgment should be applied.
